TITAN PLATE T · Timber-to-timber shear plate
Product code: TTP200
£4.57
ex VAT
· 1 per box
£5.48 inc VAT
£4.57 per unit
Not sure this is the right fixing for your connection?
Send your drawing → get a spec & quote
Want this kept in UK stock for fast delivery? Tell us. We stock more of what customers ask for. No obligation to buy; we'll let you know when it's on the shelf.
Request this in UK stock →
Delivery sorted in the basket
One clear price · FREE over £500.
FREE delivery over £500
Tracked delivery UK wide.
VAT invoice with every order
Full VAT documentation for your records
14 days to cancel after delivery
Eligible online orders · See returns policy
TITAN PLATE T is a flat plate for shear joints between timber walls or floors. It is ideal for connecting base plates to load-bearing panels and for restoring shear continuity across CLT floor panels.
- TTP300 and TTP1200 are ideal for CLT; the 1.2 m TTP1200 replaces the classic spline joint connection in panel floors
- TTP1200 can be cut into 600 mm modules with no loss of kN/m capacity
- Asymmetrical nailing on the 300 mm version allows optimised patterns on both beams and CLT
- Fastened with LBA Ø4 nails, LBS Ø5 or Ø7 screws, or LBS HARDWOOD EVO Ø7 screws
- Material: DX51D steel with Z275 zinc coating
- CE marked to EN 14545; service class SC1 and SC2
- Note: the TTP1200 version does not hold UKCA marking
Price shown is per piece. Select size to see price.
Material
Carbon steel
Coating
Galvanised / zinc coated
Product range
TITAN PLATE T
Type
Connector plate
Brand
Rothoblaas
Supplied
Per unit
Connector plateShear connectionsCLT wallsFloor & roof framingTimber-to-timberMass timber constructionTimber frame wallsPost anchoringHeavy structural connectionsConnector plate connectionsStructural connections
Technical datasheet
PDF · Opens in new tab · Download from viewer
Working out a whole connection? Get exact box quantities with our Fastener Calculator.
Open calculator →
All sizes in the TITAN PLATE T · Timber-to-timber shear plate range
Search by code or size, set quantities, and add any sizes straight to your basket.
| Code | Size | Pack | Price ex VAT | Stock | Order |
|---|---|---|---|---|---|
| TTP200 | TTP200 — 200×105×3mm | 1 pcs | £4.57 | To order | |
| TTP300 | TTP300 — 300×200×3mm | 1 pcs | £14.51 | To order | |
| TTP1200 | TTP1200 — 1200×120×1.5mm | 1 pcs | £14.88 | To order | |
