Rothoblaas ALUMIDI · Concealed beam connector
Supplied to order

Rothoblaas

ALUMIDI · Concealed beam connector

Product code: ALUMIDI80
£10.83 ex VAT · 1 per box
£13.00 inc VAT
£10.83 per unit
Total: £10.83 ex VAT
Want this kept in UK stock for fast delivery? Tell us. We stock more of what customers ask for. No obligation to buy; we'll let you know when it's on the shelf.
Request this in UK stock
Delivery and returns
Delivery sorted in the basket
One clear price · FREE over £500.
FREE delivery over £500
Tracked delivery UK wide.
VAT invoice with every order
Full VAT documentation for your records
14 days to cancel after delivery
Eligible personal purchases · Personal policy · Business policy

ALUMIDI is a concealed aluminium beam connector for timber-to-timber and timber-to-concrete joints. Hidden inside a routed slot in the beam, it gives a clean appearance and good fire behaviour while carrying vertical, lateral, axial and uplift loads, making it ideal for medium-sized floors, roofs and post-and-beam structures.

  • Concealed connection for a clean finish and improved fire performance
  • Certified strengths in all directions, suitable for inclined beams
  • Three configurations: without holes, with holes for visible fastening, and with an upper notch for top-down installation
  • The 2200 mm rod can be cut every 40 mm to make a bracket of the height required
  • Suitable for solid timber softwood and hardwood, glulam and LVL
  • Use outdoors in non-aggressive environments
  • Material: EN AW-6005A aluminium alloy
  • Service class: SC1, SC2, SC3
  • CE marked to ETA-09/0361
  • Fasten with SBD self-drilling dowels or STA dowels on the secondary beam and LBA nails or LBS screws on the main beam, supplied separately

Price shown is per connector. Select type and height to see the price.

ALU series | Product video

Material
Aluminium
Coating
None (mill-finish aluminium)
Product range
ALUMIDI
Type
Timber connector
Brand
Rothoblaas
Supplied
Per unit
Timber-to-timberTimber-to-concreteConcealed connectorBeam connectionsFloor & roof framingPost & beamMass timber constructionJoist hangers & bracketsTensile connectionsOutdoor & exposed use
Technical datasheet
PDF · Opens in new tab · Download from viewer
View datasheet
Working out a whole connection? Get exact box quantities with our Fastener Calculator. Open calculator

Choose sizes and quantities

Add several sizes to your basket in one go.

Size / product codeSold asPrice ex VATAvailabilityQuantity
Without holes / 80 mmALUMIDI80 Each £10.83each Supplied to order
Items
Without holes / 120 mmALUMIDI120 Each £14.59each Supplied to order
Items
Without holes / 160 mmALUMIDI160 Each £18.08each Supplied to order
Items
Without holes / 200 mmALUMIDI200 Each £20.53each Supplied to order
Items
Without holes / 240 mmALUMIDI240 Each £21.09each Supplied to order
Items
Without holes / 2200 mmALUMIDI2200 Each £190.93each Supplied to order
Items
With holes / 120 mmALUMIDI120L Each £14.68each Supplied to order
Items
With holes / 160 mmALUMIDI160L Each £18.28each Supplied to order
Items
With holes / 200 mmALUMIDI200L Each £19.28each Supplied to order
Items
With holes / 240 mmALUMIDI240L Each £20.69each Supplied to order
Items
With holes / 280 mmALUMIDI280L Each £26.34each Supplied to order
Items
With holes / 320 mmALUMIDI320L Each £34.42each Supplied to order
Items
With holes / 360 mmALUMIDI360L Each £39.09each Supplied to order
Items
With upper notch / 280 mmALUMIDI280N Each £34.61each Supplied to order
Items
With upper notch / 320 mmALUMIDI320N Each £37.76each Supplied to order
Items
With upper notch / 360 mmALUMIDI360N Each £41.60each Supplied to order
Items
With upper notch / 400 mmALUMIDI400N Each £46.19each Supplied to order
Items
With upper notch / 440 mmALUMIDI440N Each £51.57each Supplied to order
Items
£0.00 ex VATChoose quantities above
