Rothoblaas
ALUMAXI · Large concealed beam connector
Product code: ALUMAXI384L
£97.28
ex VAT
· 1 per box
£116.74 inc VAT
£97.28 per unit
Not sure this is the right fixing for your connection?
Send your drawing → get a spec & quote
Want this kept in UK stock for fast delivery? Tell us. We stock more of what customers ask for. No obligation to buy; we'll let you know when it's on the shelf.
Request this in UK stock →
Delivery sorted in the basket
One clear price · FREE over £500.
FREE delivery over £500
Tracked delivery UK wide.
VAT invoice with every order
Full VAT documentation for your records
Returns accepted within 30 days
Unopened stock only · Contact us first
ALUMAXI is a large concealed aluminium beam connector for timber-to-timber and timber-to-concrete joints in big floors, roofs and post-and-beam structures. Hidden inside a routed slot in the beam, it gives a clean finish and good fire behaviour while carrying heavy vertical, lateral, axial and uplift loads. It is the larger sibling of ALUMIDI, with a tapered wing profile and a higher-performance alloy that cuts weight without losing strength.
- Concealed connection for a clean finish and improved fire performance
- High certified capacity in all directions, suitable for large beams and inclined joints
- Supplied with holes for visible fastening
- Optimised tapered wing and core for around 17% less weight at unchanged mechanical performance
- Suitable for solid timber softwood and hardwood, glulam and LVL
- Use outdoors in non-aggressive environments
- Material: high-performance EN AW aluminium alloy
- Service class: SC1, SC2, SC3
- CE marked to ETA
- Fasten with SBD self-drilling dowels or STA dowels on the secondary beam and LBA nails or LBS screws on the main beam, with M16 anchors such as VIN-FIX or EPO-FIX on concrete, all supplied separately
Price shown is per connector. Select a height to see the price.
Material
Aluminium
Coating
None (mill-finish aluminium)
Product range
ALUMAXI
Type
Timber connector
Brand
Rothoblaas
Supplied
Per unit
Timber-to-timberTimber-to-concreteConcealed connectorBeam connectionsFloor & roof framingPost & beamHeavy structural connectionsMass timber constructionJoist hangers & bracketsTensile connectionsOutdoor & exposed use
Technical datasheet
PDF · Opens in new tab · Download from viewer
Working out a whole connection? Get exact box quantities with our Fastener Calculator.
Open calculator →
All sizes in the ALUMAXI · Large concealed beam connector range
Search by code or size, set quantities, and add any sizes straight to your basket.
| Code | Height | Pack | Price ex VAT | Stock | Order |
|---|---|---|---|---|---|
| ALUMAXI384L | 384 mm | 1 pcs | £97.28 | To order | |
| ALUMAXI512L | 512 mm | 1 pcs | £131.20 | To order | |
| ALUMAXI640L | 640 mm | 1 pcs | £158.72 | To order | |
| ALUMAXI768L | 768 mm | 1 pcs | £183.68 | To order | |
| No sizes match your search. | |||||
