Rothoblaas LOCK T MIDI · Concealed timber-to-timber beam connector
Supplied to order

Rothoblaas

LOCK T MIDI · Concealed timber-to-timber beam connector

Product code: LOCKT50135
£13.77 ex VAT · 1 per box
£16.52 inc VAT
£13.77 per unit
Total: £13.77 ex VAT
Want this kept in UK stock for fast delivery? Tell us. We stock more of what customers ask for. No obligation to buy; we'll let you know when it's on the shelf.
Request this in UK stock
Delivery and returns
Delivery sorted in the basket
One clear price · FREE over £500.
FREE delivery over £500
Tracked delivery UK wide.
VAT invoice with every order
Full VAT documentation for your records
14 days to cancel after delivery
Eligible personal purchases · Personal policy · Business policy

LOCK T MIDI is a concealed aluminium connector for timber-to-timber beam and post-and-beam joints. Hidden within a routed slot, it gives a clean, fire-friendly finish while carrying vertical, lateral, axial and uplift loads, making it ideal for carports, pergolas, canopies, floors and roofs. The EVO version adds a graphite-black coating for use in more aggressive environments.

  • Concealed connection for a clean appearance and good fire behaviour
  • Certified strengths in all load directions, suitable for inclined beams
  • Pre-assembles on the beam so no extra screws are needed on site
  • Two connectors of different widths can be paired for extra lateral tolerance
  • Mill finish for indoor and sheltered use; EVO graphite-black coating for aggressive outdoor environments
  • Suitable for solid timber softwood and hardwood, glulam and LVL
  • Material: EN AW-6005A aluminium alloy
  • Service class: SC1, SC2, SC3
  • CE marked to ETA-19/0831
  • LOCK connectors install as a matched pair; fasten with LBS or LBS EVO screws, supplied separately

Price shown is per box. Select finish and size to see the price.

LOCK series | Product video

Material
Aluminium
Coating
None (mill-finish aluminium)
Product range
LOCK T MIDI
Type
Timber connector
Brand
Rothoblaas
Supplied
Per unit
Timber-to-timberConcealed connectorBeam connectionsPergolas & carportsFloor & roof framingPost & beamMass timber constructionJoist hangers & bracketsTensile connectionsOutdoor & exposed use
Technical datasheet
PDF · Opens in new tab · Download from viewer
View datasheet
Working out a whole connection? Get exact box quantities with our Fastener Calculator. Open calculator

Choose sizes and quantities

Add several sizes to your basket in one go.

Size / product codeSold asPrice ex VATAvailabilityQuantity
Mill finish / 50 × 135 mmLOCKT50135 Each £13.77each Supplied to order
Items
Mill finish / 50 × 175 mmLOCKT50175 Each £16.19each Supplied to order
Items
Mill finish / 75 × 175 mmLOCKT75175 Each £20.63each Supplied to order
Items
Mill finish / 75 × 215 mmLOCKT75215 Each £23.74each Supplied to order
Items
Mill finish / 100 × 215 mmLOCKT100215 Each £29.38each Supplied to order
Items
Mill finish / 75 × 240 mmLOCKT75240 Each £27.22each Supplied to order
Items
Mill finish / 100 × 240 mmLOCKT100240 Each £33.81each Supplied to order
Items
Mill finish / 125 × 240 mmLOCKT125240 Each £40.20each Supplied to order
Items
Mill finish / 75 × 265 mmLOCKT75265 Each £29.78each Supplied to order
Items
Mill finish / 100 × 265 mmLOCKT100265 Each £36.28each Supplied to order
Items
Mill finish / 125 × 265 mmLOCKT125265 Each £43.09each Supplied to order
Items
Mill finish / 75 × 290 mmLOCKT75290 Each £29.79each Supplied to order
Items
Mill finish / 100 × 290 mmLOCKT100290 Each £38.83each Supplied to order
Items
Mill finish / 125 × 290 mmLOCKT125290 Each £46.19each Supplied to order
Items
EVO graphite black / 50 × 135 mmLOCKTEVO50135 Each £19.34each Supplied to order
Items
EVO graphite black / 50 × 175 mmLOCKTEVO50175 Each £16.66each Supplied to order
Items
EVO graphite black / 75 × 175 mmLOCKTEVO75175 Each £27.48each Supplied to order
Items
EVO graphite black / 75 × 215 mmLOCKTEVO75215 Each £30.70each Supplied to order
Items
EVO graphite black / 100 × 215 mmLOCKTEV100215 Each £37.96each Supplied to order
Items
EVO graphite black / 75 × 240 mmLOCKTEV75240 Each £59.76each Supplied to order
Items
EVO graphite black / 100 × 240 mmLOCKTEV100240 Each £69.15each Supplied to order
Items
EVO graphite black / 125 × 240 mmLOCKTEV125240 Each £75.13each Supplied to order
Items
EVO graphite black / 75 × 265 mmLOCKTEV75265 Each £65.30each Supplied to order
Items
EVO graphite black / 100 × 265 mmLOCKTEV100265 Each £72.56each Supplied to order
Items
EVO graphite black / 125 × 265 mmLOCKTEV125265 Each £79.39each Supplied to order
Items
EVO graphite black / 75 × 290 mmLOCKTEV75290 Each £67.44each Supplied to order
Items
EVO graphite black / 100 × 290 mmLOCKTEV100290 Each £75.56each Supplied to order
Items
EVO graphite black / 125 × 290 mmLOCKTEV125290 Each £83.23each Supplied to order
Items
£0.00 ex VATChoose quantities above
