Rothoblaas DISC FLAT · Removable concealed connector
Supplied to order

Rothoblaas

DISC FLAT · Removable concealed connector

Product code: DISCF55
£25.60 ex VAT · 1 per box
£30.72 inc VAT
£25.60 per unit
Total: £25.60 ex VAT
Want this kept in UK stock for fast delivery? Tell us. We stock more of what customers ask for. No obligation to buy; we'll let you know when it's on the shelf.
Request this in UK stock
Delivery and returns
Delivery sorted in the basket
One clear price · FREE over £500.
FREE delivery over £500
Tracked delivery UK wide.
VAT invoice with every order
Full VAT documentation for your records
14 days to cancel after delivery
Eligible personal purchases · Personal policy · Business policy

DISC FLAT is a fully concealed, removable steel connector for beam and column joints in timber-to-timber, timber-to-steel and timber-to-concrete configurations. A central pass-through rod clamps the elements together, so the connection resists forces in all directions and can be tightened after assembly. Ideal for hybrid structures, exposed architectural connections and demountable or temporary buildings.

  • Completely concealed joint for a clean architectural finish
  • Resists shear, lateral and axial forces in all directions via through-rod clamping
  • Can be prefabricated off-site and fastened on-site with a single bolt
  • Fully removable thanks to the pass-through rod, suitable for temporary structures
  • Suitable for solid softwood and hardwood, glulam and LVL
  • Material: S235 carbon steel, bright zinc plated (Fe/Zn5c)
  • Service class: SC1, SC2
  • CE marked under ETA-19/0706
  • Screws and bolt not included; use Rothoblaas LBS / LBS EVO screws plus a KOS bolt and washer

Price shown is per connector. Select size to see the price.

Order by Wednesday midnight. Dispatched Thursday.

Material
Carbon steel
Coating
Galvanised / zinc coated
Product range
DISC FLAT
Type
Timber connector
Service class
SC1-SC2
Brand
Rothoblaas
Supplied
Per unit
Concealed connectorBeam connectionsDemountable structuresTimber-to-timberTimber-to-metal platesTimber-to-concreteMass timber constructionShear connections
Technical datasheet
PDF · Opens in new tab · Download from viewer
View datasheet
Working out a whole connection? Get exact box quantities with our Fastener Calculator. Open calculator

Choose sizes and quantities

Add several sizes to your basket in one go.

Size / product codeSold asPrice ex VATAvailabilityQuantity
Ø55 × 10 mmDISCF55 Each £25.60each Supplied to order
Items
Ø80 × 15 mmDISCF80 Each £28.00each Supplied to order
Items
Ø120 × 15 mmDISCF120 Each £54.93each Supplied to order
Items
